CYLINDER

CRANKSHAFT / PISTON FOR KTM EXC 1996

CARBURETOR

Item numbers

SERVICE TOOL H91

54630307400

Contact

KOLBEN 360 CC 78, O MM *

54730007000

Contact

SQUARE RING 67, 5X1 250 CC

54630032000

Contact

SQUARE RING 72, 0X1, 25 300 CC

54630332000

Contact

SQUARE R. 78, 0X1, 25 360/380 CC

54730032000

Contact

WIRE LOCK RING SKA 18

54330074000

$13,72

Unit Price

PISTON PIN 18 X 44

54630033000

Contact

PISTON PIN 18 X 48

54730033000

Contact

HEX.NUT L/SH M18X1, 5

54630029000

$15,04

Unit Price

LOCK WASHER VSK 18

58132072000

$2,89

Unit Price

SPACER SLEEVE 28X38X14

54630016200

Contact

SHAFT SEAL RING 38X52X7BTSL

0760385273

Contact

BALL BEARING 6206 TNH C4

0625062064

Contact

CYL.ROLLER BEARING NJ 306 C3

58030082000

$162,74

Unit Price

WOODRUFF KEY DIN6888-5X6, 5

0888050650

Contact

*CRANKSHAFT 250 VI STROKE 69, 5

54630018300

Contact

% CRANKSHAFT 300CC STROKE 73

54630318300

Contact

CRANKSHAFT HUB 74 ''360''

54730018000

Contact

NEEDLE BEARING KBK 18X22X20

54430034000

$29,56

Unit Price

WOODRUFF KEY DIN6888-3X5X13

0888030050

$2,89

Unit Price

ROTARY SHAFT SEAL 25X35X7

0760253570

Contact

LOCKING RING VSK 12

50230029012

$2,89

Unit Price

COLLAR NUT, M12X1, RIGHT

49030021000

49030021100

$2,89

Unit Price

CONR.REP.KIT 250/300 132MM '96

54630015044

Contact

O-RING 25, 00X1, 50 NBR 70

0770250015

$1,44

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your KTM 300 EXC MARZOCCHI/OHLINS 13LT of 1996. Let us know if you have any questions.
