HANDLEBAR / CONTROLS

FRAME FOR KTM DUKE 2016

SIDE / MAIN STAND

Item numbers

FRAME CPL.

90203001100

$1 380,44

Unit Price

FOOTR. BRACKET FRONT R/S

90103039000

$87,37

Unit Price

FOOTREST BRACKET FRONT L/S

90103038000

$87,90

Unit Price

FOOTREST FRONT RIGHT CPL. (93003042000, 93003141033)
FOOTREST FRONT RIGHT CPL.

90103041033

Contact

FOOTREST FRONT LEFT CPL. (93003042000, 93003140033)
FOOTREST FRONT LEFT CPL.

90103040033

$24,66

Unit Price

FOOTREST BRACKET REAR R/S

90103049000

$68,76

Unit Price

FOOTREST BRACKET REAR L/S

90103048000

$68,23

Unit Price

REAR FOOTPEG CMPL. RIGHT

90103051033

93003151033

$30,88

Unit Price

REAR FOOTPEG CMPL. LEFT

90103050033

93003150033

$30,88

Unit Price

ENGINE CARRIER R/S

90203006000

$45,26

Unit Price

ENGINE CARRIER L/S

90203005000

$43,28

Unit Price

FOOTREST SUPPORT HOLDER, FRONT

90103038001

$13,98

Unit Price

FLANGED NUT M10X1, 25 WS14

90103038002

$2,89

Unit Price

CHAINGUIDE

90104070000

$15,30

Unit Price

SPACER CHAINGUIDE

90104066010

$4,34

Unit Price

FLANGED NUT M10X1, 25 WS14

90103038002

$2,89

Unit Price

HH COLLAR SCREW M10X1, 25X92

J025100926

$4,34

Unit Price

HH COLLAR SCREW M10X1, 25X265

J025102656

$8,96

Unit Price

ENGINE MOUNTING SCREW M10X132

90103013000

$5,80

Unit Price

SOCKET HEAD SCREW M8X25 8.8

J912080253

$1,44

Unit Price

HH COLLAR SCREW M8X105 SW12

J027081053

$2,89

Unit Price

BOLT

90103098000

$2,89

Unit Price

WASHER 8, 2X16X1, 5

J125080003

$1,44

Unit Price

BOLT FOR FOOTREST

90103044000

$5,80

Unit Price

FOOTREST RETURN SPRING

90103042000

$5,80

Unit Price

O-RING 9X1, 5

J770009015

$1,44

Unit Price

WASHER M8

J125080004

J125080005

$1,44

Unit Price

PIN 25X1, 8MM

J094018250

$1,44

Unit Price

FOOTREST LOCK PLATE 1

90103052000

$4,34

Unit Price

FOOTREST LOCK PLATE 2

90103053000

$4,34

Unit Price

PLAIN WASHER 6, 4X12X1

90103040001

$1,44

Unit Price

CAP SCREW M6X10 SS

J029060103S

$2,89

Unit Price

ANTI-ABRASIVE TAPE

90103000001

$4,34

Unit Price

ANTI-ABRASIVE TAPE

90103000002

$2,89

Unit Price

ANTI-ABRASIVE TAPE

90103000003

$5,80

Unit Price

WASHER M8

J125080005

$1,44

Unit Price

WASHER M10

J125100005

$1,44

Unit Price

HH COLLAR SCREW M10X110 WS14

J025101103

$4,34

Unit Price

MUD GUARD

90208073000

Contact

COLLAR UNDER TRAY

90508016060

$1,44

Unit Price

WASHER

90108015020

$1,44

Unit Price

HH COLLAR SCREW M6X18 SW10

J025060183

$1,44

Unit Price

CHAIN GUIDE KIT 125 DUKE

90104070010

$31,54

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
