TIMING

CYLINDER HEAD FOR KTM EXC-F 2011

OIL PUMP

Item numbers

CYLINDER HEAD CPL.

77036020444

Contact

CYLINDER HEAD GASKET 05

77030036000

$60,18

Unit Price

VALVE COVER 06

77036052100

Contact

VALVE COVER GASKET 05

77036053000

$15,43

Unit Price

VALVE COVER SCR. M6X12 WS10 07

77036055100

Contact

SEALING ELEMENT

77036054050

77036054250

$5,80

Unit Price

COVER PLATE BREATHER 05

77036052050

Contact

EJOT SPIRAL SCREW SF M5X10-K

0009050106

$2,89

Unit Price

ANGLE CONNECTOR LC8 03

60038082000

$2,89

Unit Price

O-RING 8X2 SILICONE

0770080020

$1,44

Unit Price

SPECIAL SCREW M7X73 WS 10

77036081000

$30,48

Unit Price

SPECIAL SCREW M7X40 WS10

77036080000

$4,34

Unit Price

COLLAR NUT 7X1 05

77036024000

$7,38

Unit Price

STUD 7X1 05

77036023000

$8,17

Unit Price

BUSH SUPPORT A.BRIDGE CPL '05

77036020150

Contact

NEEDLE ROLLER DIN 5402 5X9.8

0402050980

$1,44

Unit Price

OIL JET 50 M5

60030063050

$13,32

Unit Price

DOWEL(BUSH BRIDGE)7/9/8 05

77036090000

$7,38

Unit Price

VALVE GUIDE INTAKE

77036025201

Contact

VALVE GUIDE OUTLET

77036026101

Contact

CYLINDER HEAD SCREW 05

77036079000

$15,30

Unit Price

WASHER 10, 8X18, 8X1, 5

59036090000

$1,44

Unit Price

GASKET EXHAUST FLANGE 06

77036041000

$9,89

Unit Price

EXHAUST FLANGE CPL. 07

77036039000

77036039100

$78,40

Unit Price

HH COLLAR SCREW M6X20 TX30

0025060206

$4,34

Unit Price

HH COLLAR SCREW M6X25 TX30

0025060256

$4,34

Unit Price

INTAKE BOOT 06

77036044000

Contact

CLAMP D=56MM B=9MM M4X25

59030061000

$7,38

Unit Price

ENGINE BREATHER TUBE

77031050000

$18,20

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CYLINDER HEAD of your KTM 250 EXC-F SIX DAYS of 2011. Let us know if you have any questions.
