KICK STARTER

GEAR SHIFTING MECHANISM FOR KTM XCF-W 2010

COOLING SYSTEM

Item numbers

SHIFTING FORK 5TH/6TH GEAR 05

77034001000

$113,24

Unit Price

SHIFTING FORK 2ND/3RD GEAR 05

77034002000

$74,20

Unit Price

SHIFTING FORK 1ST/4TH GEAR 05

77034003000

$114,67

Unit Price

NEEDLE ROLLER DIN5402 6X14, 8

0402061480

$6,49

Unit Price

SHIFT SHAFT ASSY

77034005044

Contact

PRESSURE SPRING 0, 9MM

58038023200

$6,49

Unit Price

SLIDING PLATE

54634008044

61234008044

$16,00

Unit Price

TENSIONING SPRING 0, 8MM

56534013100

$2,59

Unit Price

SPRING GUIDE

54634020000

$9,85

Unit Price

BALL BEARING 6903 C4

0625069034

$31,16

Unit Price

SHIFT ROLLER 05

77034012000

Contact

BALL BEARING 61805 C3

0625618050

$67,20

Unit Price

RETURN SPRING 2, 2MM '95

54634014100

$10,14

Unit Price

SHIFT LOCATING DRUM CPL. 05

77034015144

$49,95

Unit Price

AH SCREW DIN6912 M6X30 8.8

0012060303

$2,59

Unit Price

HH COLLAR SCREW M6X8 TX30

0025060086

$3,89

Unit Price

SHIFT. RAIL MAIN SHAFT 250/300

54834019000

$19,58

Unit Price

SHIFTING MAIN L=93MM 05

77034019000

$21,44

Unit Price

LOCKING LEVER SPRING

77034023000

$3,89

Unit Price

LOCKING LEVER CPL. 08

77034024044

$24,58

Unit Price

SLEEVE FOR LOCKING LEVER

54634052300

$5,19

Unit Price

WASHER DIN7349-5X15X2

0349000050

$2,59

Unit Price

HH COLLAR SCREW M5X20 TX30

0025050206

$3,89

Unit Price

SHIFT LEVER CPL. 2-STROKE 2001

54734031000

$120,97

Unit Price

STEP PLATE FOR SHIFT LEVER 250

54634131000

$48,32

Unit Price

BOLT 6X25 FOR SHIFT LEVER

54634031050

$12,00

Unit Price

SHIFTING LEVER SPRING 250

54634032100

$5,19

Unit Price

STOP DISK 14X30X1

54634050000

$3,89

Unit Price

NEEDLE SLEEVE HK 1412 14X20X12

54632095000

$10,71

Unit Price

RADIAL SHAFT SEAL 14X24X6 B

0760142460

$14,14

Unit Price

STEEL WASHER 6, 4X17X3

50232050001

$8,00

Unit Price

PAIR OF WASHERS M 6 NORDLOCK

50233041000

$6,49

Unit Price

SPECIAL SCREW M6X16 WS=8 10.9

59009062016

$3,89

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
