FRONT FORK / TRIPLE CLAMP FOR KTM SX-F 2010

FRONT FORK (PARTS)

Item numbers

FORK KTM CC 250 SX/SX-F 2010

14187J0301

Contact

HH COLLAR SCREW M8X50 TX40

0025080506

$4,34

Unit Price

HH COLLAR SCREW M8X25

0025080256

$2,89

Unit Price

HH COLLAR SCREW M8X40 TX40

0025080406

$5,80

Unit Price

HH COLLAR SCREW M8X25 TX40

0025080256S

$4,34

Unit Price

AH-COLLAR SCREW M10X35 ISA45

0912100356

0032100356S

$5,80

Unit Price

O-RING 25X3, 55 NBR70 05

0770025035

$1,44

Unit Price

SCREW F. PLASTIC K60X20AL SW6

0017060204

0017060206

$4,34

Unit Price

FACTORY START

SXS07540100

Contact

HOURMETER

SXS05450600

78112920100

$79,19

Unit Price

RETAINING PLATE FOR HOUR METER

SXS05450610

Contact

HH COLLAR SCREW M6X10 TX30

0024060106

$4,34

Unit Price

EJOT PT SCREW K50X12

0081050121

$2,89

Unit Price

BOTT.FORK PLATE VMT. X=22MM OR

7720103202204

Contact

TRIPLE CLAMP X=22MM

7720103402204

7720113402204

$383,71

Unit Price

STEERING HEAD SCREW M20X1.5 SW=27

54801036000

54801036300

$15,83

Unit Price

HANDLEBAR CLAMP 28MM

59401038000

77201038000

$35,36

Unit Price

HANDLEBAR MOUNT D28MM-H32MM
HANDLEB.SUPP. D=28MM H=32MM 05

59401039032

$51,60

Unit Price

HANDLEBAR MOUNT D28MM-H37MM
HANDLEB.SUPP. D=28MM H=37MM 05

59401039037

$48,17

Unit Price

HANDLEBAR MOUNT D28MM-H42MM
HANDLEB.SUPP. D=28MM H=42MM 05

59401039042

$51,20

Unit Price

TAPERED ROLLER BEARING CPL. 06

54201081100

Contact

O-RING SUPPORT W. SEALING LIP

54601084100

77701084000

$27,31

Unit Price

STEARING HEAD GASKET TOP

54601184000

$10,02

Unit Price

CLAMP FOR SPEED CABLE D=6MM 08

7800108500004

Contact

STEERING HEAD COVER

54201086000

$12,00

Unit Price

SPECIAL SCREW M6X12, 5 WS=8

59001092050

$2,89

Unit Price

FORK PROT. L/S+R/S ORANGE

7800109410004

7800109420004

$43,68

Unit Price

STEARING HEAD REPAIR KIT

00050000930

54201081144

$125,65

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
