OIL PUMP

IGNITION SYSTEM FOR KTM RC 2016

ELECTRIC STARTER MOTOR

Item numbers

IGNITION COVER

90530002100

Contact

IGNITION COVER GASKET

90130040000

$16,31

Unit Price

STATOR CPL.

90539004000

Contact

ROTOR CPL.

90539005000

$175,94

Unit Price

PLUG INCL. O-RING

90130002010

$5,80

Unit Price

O-RING 15, 8X2, 4

J770015824

$1,44

Unit Price

PIN DOWEL 8X6, 4X14MM

90130024000

$1,44

Unit Price

HH COLLAR SCREW M5X6

J025060083S

$1,44

Unit Price

BRACKET F. STATORCABLE

90139004002

$1,44

Unit Price

SPARK PLUG CONNECT. CPL.

90139090033

Contact

GASKET SPARK PLUG CONNECT.

90139090001

$2,89

Unit Price

RUBBER GASKET SPARK PLUG

90139093001

$2,89

Unit Price

SPARK PLUG BOSCH VR6NEU M12X1.25

90239093000

93839093000

$11,60

Unit Price

CHAIN SPROCKET GUARD

90103096000

$11,74

Unit Price

HH COLLAR SCREW M6X45

J025060451

$1,44

Unit Price

HH COLLAR SCREW M6X30

J025060301

$1,44

Unit Price

SOCKET HEAD BOLT M5X0, 8X40

90530002010

$1,44

Unit Price

WASHER 10, 3X29X3, 2

J021100003

$2,89

Unit Price

FLANGED BOLT M10X1, 25X55

J025100509S

$4,34

Unit Price

SPECIAL SCREW M6X24 WS6

90104060010

$1,44

Unit Price

SUPPORT FREEWHEEL CLUTCH

90130001000

$53,58

Unit Price

TOOTHED LOCK WASHER

90130001002

$1,44

Unit Price

BOLT SOCKET M6X1

90130001001

J900000602013

$0,65

Unit Price

FREEWHEEL CLUTCH

90140026000

$137,53

Unit Price

HH COLLAR SCREW M6X20

J025060209

$1,44

Unit Price

OIL NOZZLE

90130164000

$38,93

Unit Price

COVER HT COIL

90508047000

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
