HANDLEBAR / CONTROLS

FRAME FOR KTM DUKE 2015

SIDE / MAIN STAND

Item numbers

FRAME CPL.

90103001200

Contact

FOOTR. BRACKET FRONT R/S

90103039000

$87,37

Unit Price

FOOTREST BRACKET FRONT L/S

90103038000

$87,90

Unit Price

FOOTREST FRONT RIGHT CPL. (93003042000, 93003141033)
FOOTREST FRONT RIGHT CPL.

90103041033

Contact

FOOTREST FRONT LEFT CPL. (93003042000, 93003140033)
FOOTREST FRONT LEFT CPL.

90103040033

$24,66

Unit Price

FOOTREST BRACKET REAR R/S

90103049000

$68,76

Unit Price

FOOTREST BRACKET REAR L/S

90103048000

$68,23

Unit Price

REAR FOOTPEG CMPL. RIGHT

90103051033

93003151033

$30,88

Unit Price

REAR FOOTPEG CMPL. LEFT

90103050033

93003150033

$30,88

Unit Price

ENGINE SUPPORT R/S

90103006000

Contact

ENGINE SUPPORT L/S

90103005000

Contact

FOOTREST SUPPORT HOLDER, FRONT

90103038001

$13,98

Unit Price

FLANGED NUT M10X1, 25 WS14

90103038002

$2,89

Unit Price

CHAINGUIDE

90104070000

$15,30

Unit Price

SPACER CHAINGUIDE

90104066010

$4,34

Unit Price

FLANGED NUT M10X1, 25 WS14

90103038002

$2,89

Unit Price

HH COLLAR SCREW M10X1, 25X92

J025100926

$4,34

Unit Price

HH COLLAR SCREW M10X1, 25X265

J025102656

$8,96

Unit Price

SOCKET HEAD BOLT M10X1, 5X113

90103013100

Contact

SOCKET HEAD BOLT M8X18

J912080183

Contact

HH COLLAR SCREW M8X105 SW12

J027081053

$2,89

Unit Price

AH SCREW M8X27

J020080273

$2,89

Unit Price

WASHER 8, 2X16X1, 5

J125080003

$1,44

Unit Price

BOLT FOR FOOTREST

90103044000

$5,80

Unit Price

FOOTREST RETURN SPRING

90103042000

$5,80

Unit Price

O-RING 9X1, 5

J770009015

$1,44

Unit Price

WASHER M8

J125080004

J125080005

$1,44

Unit Price

PIN 25X1, 8MM

J094018250

$1,44

Unit Price

FOOTREST LOCK PLATE 1

90103052000

$4,34

Unit Price

FOOTREST LOCK PLATE 2

90103053000

$4,34

Unit Price

PLAIN WASHER 6, 4X12X1

90103040001

$1,44

Unit Price

CAP SCREW M6X10 SS

J029060103S

$2,89

Unit Price

ANTI-ABRASIVE TAPE

90103000001

$4,34

Unit Price

ANTI-ABRASIVE TAPE

90103000002

$2,89

Unit Price

ANTI-ABRASIVE TAPE

90103000003

$5,80

Unit Price

WASHER M8

J125080005

$1,44

Unit Price

WASHER M10

J125100005

$1,44

Unit Price

HH COLLAR SCREW M10X110 WS14

J025101103

$4,34

Unit Price

CHAIN GUIDE KIT 125 DUKE

90104070010

$31,54

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the FRAME of your KTM 200 DUKE ORANGE NON ABS of 2015. Let us know if you have any questions.
