FRONT FORK / TRIPLE CLAMP FOR KTM XC 2014

FRONT FORK (PARTS)

Item numbers

FORK 150 XC 2014

24187N7101

Contact

HH COLLAR SCREW M8X50 TX40

0025080506

$4,34

Unit Price

HH COLLAR SCREW M8X25

0025080256

$2,89

Unit Price

HH COLLAR SCREW M8X40 TX40

0025080406

$5,80

Unit Price

HH COLLAR SCREW M8X25 TX40

0025080256S

$4,34

Unit Price

AH-COLLAR SCREW M10X35 ISA45

0032100356S

$5,80

Unit Price

O-RING 25X3, 55 NBR70 05

0770025035

$1,44

Unit Price

SCREW F. PLASTIC K60X20AL SW6

0017060206

$4,34

Unit Price

BOTTOM TRIPLE CLAMP CPL.

7770103212230

$447,73

Unit Price

TRIPLE CLAMP TOP X=22 BLACK

7770103412230

7770103402230

$315,86

Unit Price

STEERING HEAD SCREW M20X1.5 SW=27

54801036000

54801036300

$15,83

Unit Price

HANDLEBAR CLAMP 28MM

77201038100

77201038000

$35,36

Unit Price

HANDLEBAR MOUNT D28MM-H32MM
HANDLEB.SUPP. D=28MM H=32MM 05

59401039032

$51,60

Unit Price

HANDLEBAR MOUNT D28MM-H37MM
HANDLEB.SUPP. D=28MM H=37MM 05

59401039037

$48,17

Unit Price

HANDLEBAR MOUNT D28MM-H42MM
HANDLEB.SUPP. D=28MM H=42MM 05

59401039042

$51,20

Unit Price

TAPERED ROLLER BEARING CPL. 06

54201081100

Contact

O-RING SUPPORT W. SEALING LIP

54601084100

77701084000

$27,31

Unit Price

STEARING HEAD GASKET TOP

54601184000

$10,02

Unit Price

CLAMP F. SPEED. CABLE D=6MM 08

7800108500028

$7,38

Unit Price

STEERING HEAD COVER

78101086000

$8,57

Unit Price

SPECIAL SCREW M6X12, 5 WS=8

59001092050

$2,89

Unit Price

FORK PROTECT. L/S+R/S WHITE

7800109420028

$43,68

Unit Price

HANDLEBAR SUPPORT KIT D28/H37

00050000921

$152,58

Unit Price

STEARING HEAD REPAIR KIT

00050000930

54201081144

$125,65

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
