FRAME FOR KTM SUPER ADVENTURE 2017

SIDE / MAIN STAND

Item numbers

FRAME ''607 OA'' BLACK

6070300100033

Contact

SUB FRAME

6030300200033

$1 410,94

Unit Price

ENGINE SUPPORT R/S BLACK

6030300600033S

$151,52

Unit Price

ENGINE SUPPORTL/S BLACK

6030300500033S

$151,52

Unit Price

FOOTR. SUP. REAR L/S BLACK

6030304800033S

$189,41

Unit Price

FOOTR. SUP. REAR R/S BLACK

6030304900033S

$178,98

Unit Price

SUITCASE HOOK L/S

60312010050

$10,81

Unit Price

DAMPING RUBBER SUITCASE HOOK

60312010060

$14,77

Unit Price

SUITCASE HOOK R/S

60312011050

$10,42

Unit Price

DAMPING RUBBER SUITCASE HOOK

60312011060

$15,04

Unit Price

EXHAUST BRACKET

6030508400033S

$147,96

Unit Price

DAMPING RUBBER

61305068000

$21,90

Unit Price

BAG RAIL RI.

60712021100

BAG RAIL LE.

60712020100

Contact

SPACER CASE CLAMP LEFT

60712033000

Contact

HH COLLAR SCREW M8X30

0025080306

$4,34

Unit Price

CABLE SUPPORT KHS NR.150-47610

58111076000

$5,80

Unit Price

HH COLLAR SCREW M6X35 TX30

0025060356

$4,34

Unit Price

WASHER DIN9021-A 6, 4

0021060003

$2,89

Unit Price

RUBBER SEAT-CONTACT SURFACE

60307048000

$8,04

Unit Price

HH COLLAR SCREW M8X55 TX40

0025080556

$7,38

Unit Price

BUSHING

60305069000

60305069100

$2,89

Unit Price

PLATE RUBBER SEAT

60307040041

$14,77

Unit Price

BUSH 6.2X12X21.5

60307049000

$7,38

Unit Price

SPACER BUSH ENGINE SUPPORT

60303007000

$15,04

Unit Price

CLIP NUT M6

54603048100

$5,80

Unit Price

AH-COLLAR SCREW M10X20 ISA45

0035100209

$11,08

Unit Price

AH-COLLAR SCREW M8X25 ISA45

0035080256

$5,80

Unit Price

FOOTPEG LS+RS CPL.

60003040133

$207,62

Unit Price

FOOTREST SPRING L/S & R/S

54603041000

$7,38

Unit Price

FOOTREST RUBBER FRONT L/S 03

60003040010

$31,27

Unit Price

FOOTREST RUBBER FRONT R/S 03

60003041010

$31,27

Unit Price

PIN FOR FOOT PED 51.5X9.8 MM

54803044000

$17,54

Unit Price

WASHER DIN 125 A 10.5

0125100003

$2,89

Unit Price

FOOTREST L/S 08

78003040050

$61,63

Unit Price

FOOTREST R/S 08

78003041050

$61,63

Unit Price

FOOTREST MOUNTING

6030310109533S

$41,83

Unit Price

PIN DIN 0094-3.2X25 NIRO

0094032253

0094032250

$1,44

Unit Price

HH COLLAR SCREW M8X16 TX40 SL

0025080166S

$4,34

Unit Price

CLOSING PANEL FRONT L/S R/S 03

60003044010

$8,57

Unit Price

SELF LOCKING NUT DIN 985 M5
SELF LOCKING NUT DIN0985-M 5

0985050003

$2,89

Unit Price

SPACER FUEL TANK 05

61007014000

$9,36

Unit Price

BUSHING MONOSHOCK SOCKET 05

60004030151

$22,43

Unit Price

SCREW M14X1, 5 L=73MM 03

60004017000

$7,38

Unit Price

CHAIN GUIDE

60303070000

$14,64

Unit Price

HH COLLAR SCREW M6X15 TX30

0024060156

$4,34

Unit Price

HEXAGON NUT DIN934 M8
HEXAGON NUT DIN0934-M 8

0934080003

$2,89

Unit Price

BUMP RUBBER M8X25MM

58303070100

$8,30

Unit Price

RANGE CHANGE METAL NUT M5

54603048200

$7,38

Unit Price

SPACER CASE CLAMP RIGHT

60712034000

Contact

SPECIAL SCREW M5X12

69008021160

$5,80

Unit Price

AH-COLLAR SCREW M10X50 ISA45

0035100509S

$10,02

Unit Price

SPACER BUSHING 20X17X8, 2

60703002058

Contact

AH COLLAR SCREW M10X24 ISA45
SHCS M10X24 TX45

0035100249

$4,34

Unit Price

ENGAGE PANEL FOOTREST L/S 03

60003152000

$7,38

Unit Price

ENGAGE PANEL FOOTREST R/S 03

60003052000

$7,38

Unit Price

FOOTREST CPL. L/S REAR 03

60003050000

$86,71

Unit Price

FOOTREST CMPL. R/S REAR 03
FOOTREST CPL. R/S REAR 03

60003051000

$87,37

Unit Price

FOOTREST BOLT, REAR

60003044100

$11,34

Unit Price

RETAINING WASHER DIN 6799 - 6

0799060003

$1,44

Unit Price

TRIPLECLAMP-FACEPLATE BELOW

60308024200

$23,35

Unit Price

SPECIAL SCREW M6X15X3

83008000015

$4,34

Unit Price

SKID PLATE ADV

6030319000030

$96,48

Unit Price

HH COLLAR SCREW M6X40 TX30

0025060406

$4,34

Unit Price

COLLAR BUSHING 6, 3X8X13X9, 5

45239060050

$7,38

Unit Price

VIBRATION DAMPER 03

60003096000

$4,34

Unit Price

STEARING HEAD COVER

60303003010

$14,11

Unit Price

RAIL-INTAKE RI.

6071201405030

Contact

RAIL-INTAKE LE.

6071201305030

Contact

DISTANCE RUPPER AIRBOX 03
DISTANCE RUBBER AIRBOX 03

60006001021

$2,89

Unit Price

HH COLLAR SCREW M8X40 TX40

0025080406

$5,80

Unit Price

CROSS CONNECTION

60712055000

Contact

AH-COLLAR SCREW M8X25 ISA45

0035080256

$5,80

Unit Price

INT. TORX OVAL HEAD M5X16

0018050163

$1,44

Unit Price

CONNECTION COMPONENT WITH SEAL

60712055155

Contact

O-RING 8.00X1.00 NBR

0770080010

Contact

SHAFT SEAL RING17X10X3 NBR

0760171030

$4,34

Unit Price

SERVICE-KIT CASE BAR

60712099000

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
