FRAME

REAR SUB FRAME FOR KTM SUPERDUKE 2017

SIDE / MAIN STAND

Item numbers

SUBFRAME

6140300210033

61503002000C1

$1 429,81

Unit Price

CROSS STIFFENER BACK

6140300213091

$235,08

Unit Price

HH COLLAR SCREW M8X16 TX40 SL

0025080166S

$4,34

Unit Price

WASHER DIN 125 A -8.4

0125080003

$1,44

Unit Price

QUICK RELEASE RUBBER GROMMET

47106003160

$5,80

Unit Price

SCREW FOR EXPANSION TANK
SCREW F. EXPANSION TANK

69013099050

$5,80

Unit Price

SEAT LOCK PLATE

61407050050

$42,89

Unit Price

SPRING F. REAR SEAT LOCK

69008025080

$5,80

Unit Price

PLUG SFL 22X0, 8-3, 0

61303088000

$1,44

Unit Price

SHELL KIT SIDECASE

61403002055

$155,09

Unit Price

BUSHING 8.4X12X21.5

61407049000

$10,55

Unit Price

WAVE SPRING

61403002032

$11,47

Unit Price

AH SCREW DIN7984-M 6X10

0984060103

$1,44

Unit Price

RUBBER BUSH 05

61013013000

$4,34

Unit Price

HH COLLAR SCREW M8X60 TX40

0025080606

$4,34

Unit Price

RUBBER SEAT-CONTACT SURFACE

60307048000

$8,04

Unit Price

HH COLLAR SCREW M8X35 TX40

0025080356

$5,80

Unit Price

LEFT PILLION STEP HOLDER

6140304800033S

$221,22

Unit Price

LEFT PILLION HEEL GUARD

6140304805033S

$100,70

Unit Price

RIGHT PILLION STEP HOLDER

6140304900033S

$221,22

Unit Price

RIGHT PILLION HEEL GUARD

6140304905033S

$115,62

Unit Price

HH COLLAR SCREW M6X12 TX30

0025060126

$4,34

Unit Price

SHCS M8X20 TX45

0035080206S

$7,51

Unit Price

FOOTRAST BACK LEFT CPL.

6900305003333S

6900305013333S

$65,99

Unit Price

FOOTRAST BACK RIGHT CPL.

6900305103333S

6900305113333S

$65,99

Unit Price

FOOTREST BOLT, REAR

60003044100

$11,34

Unit Price

ENGAGE PANEL FOOTREST R/S 03

60003052000

$7,38

Unit Price

ENGAGE PANEL FOOTREST L/S 03

60003152000

$7,38

Unit Price

RETAINING WASHER DIN 6799 - 6

0799060003

$1,44

Unit Price

AH COLLAR SCREW M10X24 ISA45
SHCS M10X24 TX45

0035100249

$4,34

Unit Price

WASHER DIN 125 A 10.5

0125100003

$2,89

Unit Price

RUBBER MOUNTING

61414040010

$7,78

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
