FUEL PUMP

PLASTICS FOR KTM SUPERDUKE 2015

STICKERS

Item numbers

REAR FAIRING L/S

6130804100028A

$309,40

Unit Price

REAR FAIRING R/S

6130804200028A

$309,40

Unit Price

TAIL END LOWER PART

61308018000

$127,24

Unit Price

REAR FAIRING LOWER PART BLACK

6130804000033

$18,34

Unit Price

EJOT PT SCREW K50X14

0081050141

$1,44

Unit Price

CLIP NUT M5

69008021080

$4,34

Unit Price

MASK REAR PANEL

61314060000

$17,94

Unit Price

MASK MIDDLE PART

61314061000

$19,00

Unit Price

MASK SPOILER L/S ORANGE 14

61308003000EBA

$138,46

Unit Price

MASK SPOILER R/S ORANGE 14

61308004000EBA

$138,46

Unit Price

HH COLLAR SCREW M6X25 TX30

0024060256

$4,34

Unit Price

RUBBER SLEEVE 7X10, 8X16MM

76014069051

$2,89

Unit Price

COLLAR BUSHING 6, 2X7, 5X13X12

76014062000

$4,34

Unit Price

SPECIAL SCREW M5X12

69008021160

$5,80

Unit Price

BOLT 8X12X16MM

61313057000

$8,04

Unit Price

EJOT PT SCREW K50X12

0081050121

$2,89

Unit Price

SECURING CLIP D=8MM 03

60013058000

$2,89

Unit Price

SPECIAL SCREW M5X17

69008021060

$4,34

Unit Price

FENDER FRONT ORANGE 2014

61308010000EBA

$203,14

Unit Price

REAR FENDER BLACK

6130801100033

$39,35

Unit Price

BLIND PLUG NUT M5 WN16A

60008008050

$5,27

Unit Price

REARFENDER

61304050000

61304050100

$67,31

Unit Price

PVC-CLAMP HEYCO 13, 9 3379

69007029000

$4,34

Unit Price

SPLASH PROTECTION AUSTRALIA

61308123010

Contact

WASHER DIN0125-A 5, 3

0125050003

Contact

SELF LOCKING NUT DIN 985 M5
SELF LOCKING NUT DIN0985-M 5

0985050003

$2,89

Unit Price

WASHER 6MM

40006006000

$1,44

Unit Price

OVAL HEAD SCREW DIN0966-M 5X16

0966050163

$1,44

Unit Price

SIDE REFLECTOR RED REAR

16512180100

$10,02

Unit Price

SPLASH PROTECTION

61308023010

$11,74

Unit Price

SCREW FOR PLASTIC K50X18 T20

0081050181

$2,89

Unit Price

HH COLLAR SCREW M6X15 TX30

0024060156

$4,34

Unit Price

NUMBER PLATE CARRIER UPP. PART

61308022000

$68,23

Unit Price

NUMBER PLATE CARRIER LOW. PART

61308023000

$68,63

Unit Price

BRACKET SIDE REFLECTOR 06

62512081000

$39,46

Unit Price

LICENCE FITTING

60012081200

60012081300

$11,87

Unit Price

BRACKET FOR REFLECTOR

58412080050

$8,57

Unit Price

REAR REFLECTOR RED

58412080000

58412080400

$7,38

Unit Price

HH COLLAR NUT M10X1, 25 WS=13

58414030000

$2,89

Unit Price

LOCK WASHER DIN6797-J10, 5 ZI

0797100003

$1,44

Unit Price

WASHER DIN0433-M10
WASHER 18X10, 5X1, 6

0433100003

$1,44

Unit Price

SELF LOCK. NUT DIN985-M6-A2
SELF LOCK. NUT DIN0985-M 6

0985060003

$2,89

Unit Price

WASHER DIN9021-A 6, 4

0021060003

$2,89

Unit Price

SPECIAL SCREW M6X15X5, 5

83008100015

$4,34

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the PLASTICS of your KTM 1290 SUPER DUKE R ORANGE ABS of 2015. Let us know if you have any questions.
