OIL PUMP

IGNITION SYSTEM FOR KTM DUKE 2020

ELECTRIC STARTER MOTOR

Item numbers

IGNITION COVER CMPL.

93130102033

Contact

IGNITION COVER GASKET

93530040100

$5,80

Unit Price

STATOR LOOSE

93139004000

Contact

ROTOR, LOOSE

93139005000

Contact

PLUG INCL. O-RING

90130002010

$5,80

Unit Price

O-RING 15, 8X2, 4

J770015824

$1,44

Unit Price

PIN DOWEL 8X6, 4X14MM

90130024000

$1,44

Unit Price

HEX COLLAR SCREW M5X8

J025050081

$1,44

Unit Price

BRACKET F. STATORCABLE

90139004002

$1,44

Unit Price

GASKET SPARK PLUG CONNECT.

90139090001

$2,89

Unit Price

SEALING BOOT SPARK PLUG

93839091000

$1,44

Unit Price

SPARK PLUG BOSCH VR6NEU M12X1.25

90239093000

93839093000

$11,60

Unit Price

CHAIN SPROCKET GUARD

90103096000

$11,74

Unit Price

HH COLLAR SCREW M6X45

J025060451

$1,44

Unit Price

HH COLLAR SCREW M6X30

J025060301

$1,44

Unit Price

AH SCREW M5X35 SELF LOCKING

J912050353S

$1,44

Unit Price

SCREW DRIVE GEAR KIT

90130018044

Contact

SPECIAL SCREW M6X24 WS6

90104060010

$1,44

Unit Price

SUPPORT FREEWHEEL CLUTCH

90130001000

$53,58

Unit Price

TOOTHED WASHER M6

J797060003

$1,44

Unit Price

BOLT SOCKET M6X1

90130001001

J900000602013

$0,65

Unit Price

FREEWHEEL CLUTCH

90140026000

$137,53

Unit Price

HEXAGON SCREW M6X35

J912060353

$1,44

Unit Price

OIL NOZZLE

90130164000

$38,93

Unit Price

COVER INGITION COIL

93039010000

$2,89

Unit Price

SLEEVE COVER IGNITION COIL

93039011000

$1,44

Unit Price

COIL ASSEMBLY IGNITION

93039006033

$53,58

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the IGNITION SYSTEM of your KTM 125 DUKE ORANGE - B.D. of 2020. Let us know if you have any questions.
