CYLINDER

CRANKSHAFT / PISTON FOR KTM DUKE 2011

CLUTCH

Item numbers

CRANKSHAFT CPL.

90130018000

Contact

BALL BEARING 63/2/8 HN3CNP

90130082000

$32,46

Unit Price

DRIVE WHEEL CRANKSH. F. AGW

90130018006

$54,77

Unit Price

BELLEVILLE SPRING

90130018007

Contact

NUT FOR DRIVE WHEEL AGW

90130018008

$8,96

Unit Price

SPACER SHIM

90130018003

$5,80

Unit Price

PRIMARY GEAR 22T.

90132024000

$39,85

Unit Price

TIMING GEAR 17 T.

90136014017

$14,64

Unit Price

WASHER PRIMARY DRIVE GEAR

90130029050

$1,44

Unit Price

SLOTTED NUT M14X1 H=7

J080414107

Contact

WOODRUFF KEY 4X5X13

J888040050

$2,89

Unit Price

SCREW DRIVE GEAR KIT

90130018044

Contact

CONNECTING ROD CPL.

90130015000

Contact

CONNECTING-ROD BOLT

90130015001

Contact

NUT F. CONNECTING-ROD BOLT

90130015002

Contact

CON ROD BEARING SHELL

90130015010

Contact

CON ROD BEARING SHELL GREEN

90130015011

Contact

CON ROD BEARING SHELL BLUE

90130015012

Contact

PISTON CPL.

90130007000

Contact

PISTON RING CPL.

90130030010

Contact

PISTON BOLT

90130033000

Contact

CIRCLIP

90130074000

Contact

CRANKSHAFT REPAIR KIT

00050002314

90130018088

$93,84

Unit Price

PISTON KIT 125 DUKE 11-13

00050000210

Contact

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.

Find on this page all the original spare parts relating to the CRANKSHAFT / PISTON of your KTM 125 DUKE ORANGE of 2011. Let us know if you have any questions.
