FUEL PUMP

PLASTICS FOR KTM RC8 2009

STICKERS

Item numbers

FAIRING SCREEN HIGH 08

69008008000

Contact

FR.FAIR.UP.PART L/S WH. GL RC8

6900800100020A

Contact

FR.FAIR.UP.PART R/S WS.GL.RC8

6900800200020A

Contact

FR.FAIR.LO.PART L/S WHI.M. RC8

6900800300027A

Contact

FR.FAIR.LO.PART R/S WHI.M. RC8

6900800400027A

$315,86

Unit Price

EXIT-AIR SHAFT L/S BL.MATT RC8

6900805200033A

Contact

EXIT-AIR SHAFT R/S BL.MATT RC8

6900805300033A

$365,00

Unit Price

COOLER FAIRING L/S WS.GL. RC8

6900805000020A

Contact

COOLER FAIRING R/S WS.GL. RC8

6900805100020A

Contact

FRESH-AIR SHAFT L/S BL. MA. 10

6900802200033

6900802210033

$81,96

Unit Price

FRESH-AIR SHAFT R/S BLACK MATT

6900802300033

6900802310033

$70,92

Unit Price

UP. FRESH-AIR SHAFT BLACK MA.

6900802100033

6900802120033

$12,13

Unit Price

FRONT FENDER BLACK 07

6110801000030

Contact

SIDE COVER L/S BL. BR. RC8

6900804300030A

$140,35

Unit Price

SIDE COVER R/S BL. GL. RC8

6900804400030A

Contact

REAR FAIRING L/S BL. BR. RC8

6900804100030A

Contact

REAR FAIRING R/S BL. BR. RC8

6900804200030A

$374,08

Unit Price

REAR LIGHT ADAPTER R/S

69008039000

$10,55

Unit Price

REAR LIGHT ADAPTER L/S

69008038000

$10,55

Unit Price

UPPER REAR END PANEL

6900803100033

$22,56

Unit Price

LICENSE PLATE BRACKET LO. PART

69008018000

Contact

LICENSE PLATE BRACKET UP. PART

69008017000

Contact

SPECIAL WASHER

61108045000

$5,80

Unit Price

CAP HEAD BOLD ISO 14580 M6X16
SHCS ISO 14580 M6X16

014580060166

$2,89

Unit Price

CLIP NUT M5

69008021080

$4,34

Unit Price

SPECIAL SCREW M5X17

69008021060

$4,34

Unit Price

BLIND PLUG NUT M5 WN16A

60008008050

$5,27

Unit Price

HH COLLAR SCREW M5X16 TX30

0025050166

$2,89

Unit Price

SPREAD RIVET CMPL. 6.2MM
SPREAD RIVET CPL. 6, 2MM

76503075000

$4,34

Unit Price

HH COLLAR SCREW M6X13 TX30

0024060136

$4,34

Unit Price

SCREW TORX M5X10 05

58605083010

Contact

WASHER TAIL SECTION UT D=14MM
WASHER REAR-UT D=14MM

75008023000

$4,34

Unit Price

RUBBER GROMMET D=8MM OPEN

31008060000

$2,89

Unit Price

HH COLLAR SCREW M8X20

0025080206

$2,89

Unit Price

WASHER F. MONT.REARPART 11

6900300405001

6930300405001

$10,02

Unit Price

EJOT PT SCREW K50X16 1451

0081050161

$1,44

Unit Price

RUBBER SLEEVE 10X14X20 08

69014078000

$2,89

Unit Price

PASSENGER?S SEAT PLATE KIT
PASSENGER´S SEAT PLATE KIT

69007047050

$22,30

Unit Price

SCREW FOR PLASTIC K40X16 T20

0081040161

$1,44

Unit Price

HH COLLAR SCREW M6X25 TX30

0025060256

$4,34

Unit Price

COLLAR BUSH. 6, 2X10X21X14MM 08

69007028000

$7,38

Unit Price

HH COLLAR SCREW M6X20 TX30

0025060206

$4,34

Unit Price

BUSHING LICENSE PLATE BRACKET

69008020000

$5,80

Unit Price

HH COLLAR SCREW M5X20 TX30

0025050206

$2,89

Unit Price

CLIP NUT M6

54603048100

$5,80

Unit Price

LICENCE FITTING

60012081200

60012081300

$11,87

Unit Price

HH COLLAR SCREW M6X15 TX30

0024060156

$4,34

Unit Price

WASHER DIN9021-A 6, 4

0021060003

$2,89

Unit Price

SELF LOCK. NUT DIN985-M6-A2
SELF LOCK. NUT DIN0985-M 6

0985060003

$2,89

Unit Price

OVAL HEAD SCREW DIN0966-M 5X16

0966050163

$1,44

Unit Price

WASHER 6MM

40006006000

$1,44

Unit Price

WASHER DIN0125-A 5, 3

0125050003

Contact

SELF LOCKING NUT DIN 985 M5
SELF LOCKING NUT DIN0985-M 5

0985050003

$2,89

Unit Price

REAR REFLECTOR RED

58412080000

58412080400

$7,38

Unit Price

BRACKET FOR REFLECTOR

58412080050

$8,57

Unit Price

EDGE PROTECTOR 14X9, 5X66 MM 06

60114010070

$4,34

Unit Price

EJOT PT SCREW K60X12 1451

0081060121

$2,89

Unit Price

WASHER PA 8, 3X12X5

69008003050

$4,34

Unit Price

WASHER DIN9021-A 4, 3

0021040003

$1,44

Unit Price

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from KTM. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
When adding a part to your cart, be careful to order the required quantity. Please note that the unit price indicated is the price for each part number in quantity 1.
Our parts are original and brand new spare parts of KTM, to guarantee you quality and durable components. If you have any questions, we are here to help. Order your spare parts today and receive them directly at home!
